Thermal Imaging Scope
  • Thermal Imaging Scope
  • Thermal Imaging Scope
  • Thermal Imaging Scope
  • Thermal Imaging Scope
  • Thermal Imaging Scope
Thermal Imaging Scope
$135.75 $288.00
Details
  • Advanced Detector: Utilizes a vanadium uncooled oxide detector with 640x512 resolution and 12μm pixel spacing, offering <35mK NETD at f/1.0 300K for superior thermal sensitivity, and an image frame frequency of 50Hz with a response band of 8~14μm.
  • Image Processing: Employs digital filtering for noise reduction and maintains a 50Hz image frame rate (PAL), ensuring clear and stable thermal imaging.
  • Lens Specifications: Features a 50mm focal length lens with f/1.0 aperture, providing a field of view of H:8.783° V:7.032° for wide and precise observation.
  • Eyepiece Screen: Equipped with a 0.39-inch OLED display at 1024x768 resolution for high-clarity viewing.
  • Thermal Image Adjustment: Offers 4 pseudo-color modes (Black-hot, White-hot, Red-hot, Iron red), manual gain adjustment, and digital magnification options of 1x, 2x, 4x, 8x for customizable viewing.
  • Battery and Power: Powered by 1pc 18500 battery (3.7V/2400mAh), providing about 6 hours of battery life and 3 hours charging time.
  • Environmental Parameters: Operates in temperatures from -20°C to +60°C and stores from -40°C to +70°C, suitable for harsh conditions.
  • Physical Parameters: Weighs 550g and measures 170x50x75mm, with external interfaces including a custom ranging interface and CVBS analog video output port.
Item Name Thermal Imaging Rifle Scope
Detector Type Uncooled Vanadium Oxide Detector
Resolution 640 x 512
Pixel Interval 12μm
NETD Less than 35mK (25°C, F#=1.0)
Frame Rate 50Hz
Response Waveband 8μm to 14μm
Focal Length 50mm
Aperture F1.0
Field of View 8.8° x 7.0°
Display 1024x768, 0.39inch, OLED
Palettes White Hot, Black Hot, Red Hot, Fusion
Basic Magnification 2.6x
Electronic Magnification 1x, 2x, 4x, 8x
Battery Type Replaceable 18500 lithium battery
Battery Operating Time Around 6h
Weight 550g
Dimension 170 x 60 x 75mm
